Industrial Metering Cubical

Name: Industrial Metering Cubical
Brand: NEMR INDUSTRIES PRIVATE LIMITED
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Industrial Metering Cubical Specification

Operating Voltage
415 V AC Volt (V)

Rated Insulation Voltage
690 V

Control System
Manual

Protection Class
Class I

Cover Material
Other

Features
Rust Proof, Long Life, Easy Maintenance, Weatherproof

Base Material
Other

Rated Operation Voltage
415 V

Cabinet Material
Mild Steel

Current Rating
400A

Panel Type
Outdoor/Indoor

Protection Level
IP55

Way
Single/Double

Rated Current
400A Ampere (amp)

Thickness
2 mm Micrometers (um)

Components
Energy Meter, MCCB, Busbar, CT/PT, Indicator Lamp

Connectivity Type
Cable Entry Top/Bottom

Cooling System
Natural Air Cooling

Product Type
Other

Material
Mild Steel

Surface Finish
Powder Coated

Standard
IS/IEC 61439

Surface Color
Any Color

Rated Voltage
415 V AC Volt (V)

Frequency (MHz)
50 Hz Hertz (HZ)

Maximum Output Current
400A Ampere (amp)

Dimension (L*W*H)
1800 x 900 x 600 mm Millimeter (mm)

Application
Electrical Power Distribution and Metering

IP Rating
Ip54

Display Type
Digital

Mounting Type
Floor Mounted

Earthing Provision
Provided

Door Type
Double Door with Lock & Key

Busbar Material
Electrolytic Copper

Cable Entry
Top/Bottom

Maximum Fault Level
25 kA for 1 sec

Operating Temperature
-10C to +55C

Inspection Window
Provided

Number of Meters
Up to 4

Industrial Metering Cubical Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Industrial Metering Cubical

Explore our preeminent Metering Cubical, crafted with superlative electrolytic copper busbars designed for a maximum fault level of 25 kA for 1 second. Built from rustproof, powder-coated mild steel (MS) with a crackerjack IP55 protection rating, this unit is engineered for both indoor and outdoor use across India. Featuring advanced components-energy meter, MCCB, CT/PT, and more-plus easy maintenance, dual cable entry, and a double door with lock and key. Grab yours and seize this exclusive offer for reliable, long-life power distribution and metering solution today!

Key Features and Applications of Metering Cubical

The Metering Cubical delivers superlative performance for electrical power distribution and precise metering. Its robust construction with a powder-coated, rust-proof finish ensures reliability in any environment, while the double-door design enhances both security and accessibility. Suitable for commercial complexes, industrial sites, and utility spaces, it supports up to four meters and accommodates floor-mount installation. Application is simple: connect via top or bottom cable entry for seamless integration into your existing power systems, ensuring effective energy management and safe operations.

Sampling, Policy, and Certifications for Metering Cubical

We provide sample units of our Metering Cubical upon proposal amount approval, making the drop-off process convenient for your team. Leveraging express shipping options across India, samples reach you swiftly and securely. Our product is manufactured to conform to IS/IEC 61439 standards, assuring top-tier reliability and safety. Regulatory documentation and certifications are readily available upon request, enabling you to evaluate the build quality and compliance before making your procurement decisions.

FAQ's of Metering Cubical:

Q: How is the Metering Cubical installed and what are the cable entry options?

A: The Metering Cubical is designed for floor-mounted installation and supports both top and bottom cable entry. This provides flexibility and seamless integration into various electrical setups.

Q: What materials are used for constructing the Metering Cubical, and how does this benefit users?

A: Manufactured from powder-coated mild steel (MS) and base CRCA sheet, the cubical is rust-proof and offers enhanced durability. Electrolytic copper busbars grant superior conductivity, ensuring long-lasting, reliable performance for power distribution.

Q: What applications are suitable for the Metering Cubical?

A: This product is ideal for electrical power distribution and metering in industrial facilities, commercial buildings, and utility substations, accommodating both general and specific energy management needs.

Q: Which safety and protection features are included in the Metering Cubical?

A: It offers IP55 weatherproof protection, Class I safety classification, double-door entry with lock and key, earthing provision, and robust MCCB and CT/PT devices for secure operation in demanding environments.

Q: What is the process to request a sample and what certifications are provided?

A: To request a sample, submit your proposal amount for processing. Samples can be delivered via drop-off or express shipping. The product is certified under IS/IEC 61439, ensuring strict compliance and quality assurance.

Q: When should I consider upgrading to this Metering Cubical?

A: Upgrade when you require improved safety, reliability, and easy maintenance in your power distribution network, especially if working in environments with harsh conditions or multiple metering needs.
